B Specifications
276 July 29, 2013, 715003794 Rev. B
Physical specifications
Environmental specifications
Electrical specifications
Physical specifications:
Item Specification
Height 57.1 cm (22.5 inches)
Depth 57.1 cm (22.5 inches); 64.8 cm (25.5 inches) with
optional sample heater/cooler
Width 45.7 cm (18 inches); 58.4 cm (23.0 inches) with
optional column heater or column heater/cooler
Weight 48.5 kg (107 lb)
62.1 kg (137 lb) with optional sample
heater/cooler and column heater (or
heater/cooler) module
Wetted surface materials 316 stainless steel, ruby, sapphire, MP35N,
PEEK, PPS, UHMWPE, Tefzel
®
(ETFE), Teflon
®
(FEP and PTFE), Teflon AF
®
, Fluoroloy G,
Fluoroloy-08R
Environmental specifications:
Item Specification
Operating temperature 4 to 40° C (39 to 104° F)
Relative humidity 20 to 80%, noncondensing
Acoustic noise < 65 dB(A)
Solvent compatibility (see
Appendix D)
Solvents consistent with materials of
construction. Salts and buffers can reduce seal
life, especially at pressures in excess of 3000 psi.
Electrical specifications:
Item Specification
Power requirements 950 VA (maximum)
