Firmware and software requirements
July 29, 2013, 715003794 Rev. B 47
Typical system dimensions for the e2695 Separations Module:
The top panel of the separations module can support the weight of two
detectors, the detector drip tray, and the solvent bottle tray with four filled
solvent bottles. Be sure to provide leak protection below any fluid-carrying
units you place on top of the separations module.
Firmware and software requirements
The Waters detectors that connect to the separations module must meet
minimum firmware requirements to successfully communicate with the
Installation site requirements:
Factor Requirement
Temperature 4 to 40 °C (39 to 104 °F)
Relative humidity 20 to 80%, noncondensing
Bench space Width: 45.7 cm (18 inches). With
optional column heater or column
heater/cooler, 58.4 cm (23 inches).
Depth: 57.1 cm (22.5 inches). With
optional sample heater/cooler, 64.8 cm
(25.5 inches)
Height: 57.1 cm (22.5 inches)
Level to within ±2°
Vibration Negligible
Clearance At least 16 cm (6 inches) at rear for
ventilation
Static electricity Negligible
Power Grounded AC, 100 - 240 Vac, 50 - 60 Hz
Electromagnetic
fields
No nearby source of electromagnetic
noise such as arcing relays or electric
motors
Caution: To avoid overheating the separations module, provide at least
16 cm (6 inches) of clearance at the rear of the separations module.
