B Specifications
278 July 29, 2013, 715003794 Rev. B
Chart output Two terminals (+, –) for recording the following
user-selectable outputs:
Programmed flow rate
Sample loop pressure
System pressure
Primary head pressure
Programmed composition (%A, %B, %C, %D)
Sample temperature
Column temperature
Degasser vacuum
Run stopped Contact closure indicating:
Sample set is suspended
Current function is suspended
Maximum allowable current = 0.5 A. Maximum
allowable voltage = 30 Vdc. Contact resistance =
0.2 ohms.
Inject start Contact closure (across terminals 1 and 2) for 1
second on injection.
Maximum allowable current = 0.5A. Maximum
allowable voltage = 30 Vdc. Contact resistance =
0.2 ohms.
Ground terminals Connected to signal ground and used as
reference for outputs
Electrical specifications: (Continued)
Item Specification
