Vials and low volume inserts
July 29, 2013, 715003794 Rev. B 287
Caution: The separations module is factory-set to accept vials with a
bottom thickness of 1.6 mm or less. Any vial with a thickness greater
than 1.6 mm requires a positive syringe draw depth offset. Failure to
ensure that offset can cause vial breakage or needle damage.
Separations module vials and low volume inserts:
Part
number
Description
Average
thickness
Offset Comments
WAT270946 Screw cap glass
vial
0.93 mm 0 Add at least 1 mm
offset when using LVI
WAT094169 Screw cap glass
vial
2.05 mm >
1 mm Do not use LVIs with
this vial
WAT094217 Snap/crimp cap
vial
1.41 mm 0 Do not use LVIs with
this vial
WAT094219 Snap cap glass
vial
1.59 mm 0 Add at least 1 mm
offset when using LVI
WAT094222 Snap/crimp cap
vial
1.72 mm >
1 mm Variable thickness;
add at least 1 mm
offset when using LVI
WAT094172 Screw cap “V”
vial
1.46 mm 0 Low-volume (250 µL)
vial
WAT094170 Low Volume
Insert (300 µL)
0.61 mm N/A Use this insert with
vials that have a neck
opening >
6 mm
WAT094171 Low Volume
Insert (150 µL)
0.71 mm N/A Use this insert with
vials that have a neck
opening >
6 mm
WAT063300 Screw cap glass
vial
0.93 mm 0 Add at least 1 mm
offset when using
LVIs
WAT210686 Screw cap glass
vial
2.05 mm >
1 mm Do not use LVIs with
this vial
WAT210683 Screw cap glass
vial
2.05 mm >
1 mm Do not use LVIs with
this vial
