Waters Alliance e2695 - Page 70

2 Install the e2695 Separations Module
70 July 29, 2013, 715003794 Rev. B
Connect signal cables:
No
Yes
Start
Signal
connections
complete
No
Yes
Connect to
non-Waters data
system?
Install RS-232
cable
No
Yes
Connect to non-IEEE,
non-Ethernet detector
or an external auto-
sampler?
Install event and
I/O cable(s)
Connect to
IEEE-488 bus?
Install IEEE-488
cable
Connect to
Ethernet bus?
No
Yes
Install Ethernet
cable
