WM 68401 04/2021
MEDUCORE Standard
2
EN 185
6 Operation
3. Select the NIBP cuff which is suitable for the patient's limb as
per the following table:
When doing so, please note:
• The index printed on the NIBP cuff must be within the
printed range (Range).
• If the index marking does not extend into the printed range
(Range): Select a larger NIBP cuff.
• If the index marking extends beyond the printed range
(Range): Select a smaller NIBP cuff.
• For disposable NIBP cuffs for newborns: Use adapter tube
(WM 45467).
Designation Color Limb circumference
Thigh
Thigh Brown 38 cm-50 cm
Upper arm
Large Adult plus Dark red 40 cm-55 cm
Adult plus Dark blue 28 cm-40 cm
Adult Dark blue 23 cm-33 cm
Small Adult Turquoise 17 cm-25 cm
Child Green 12 cm-19 cm
Infant Orange 8 cm-13 cm
RANGE
Right sizeSelect a smaller
one
Select a larger
one
Select a smaller
one
