Weinmann MEDUCORE Standard2 User Manual

WM 68401 04/2021
MEDUCORE Standard
2
EN 259
10 User menu
10.3.2 ECG settings
10-3 ECG settings submenu
Parameter Possible values Description Factory setting
Amplitude scaling
Autom.
2 mm/mV
5 mm/mV
10 mm/mV
20 mm/mV
Here you can set the amplification
of the ECG signal and thus the
height of the ECG curve.
If the Autom. setting has been
selected, the amplification of the
ECG signal and thus the height of
the ECG curve are adapted
automatically so that a maximum
height for lead II is displayed.
Autom.
Feed rate
12.5 mm/s
25 mm/s
50 mm/s
Here you can set the feed rate of the
ECG curve display and so change
the time resolution.
25 mm/s
Line filter
Activated
Deactivated
By activating the line filter, you can
reduce ECG interference caused by
the power supply network.
Activated
