13 Operator menu
13.10.2 Possible values
Parameter
Possible
values
Description
Factory
setting
Low-pass filter -
50 Hz
150 Hz
Here you can set a low-pass
filter to filter out artifacts.
150 Hz
Amplitude scaling -
2 mm/mV
5 mm/mV
10 mm/mV
20 mm/mV
Here you can set the
amplification of the ECG
signal and thus the height of
the ECG curve.
10 mm/mV
Feed rate -
12.5 mm/s
25 mm/s
50 mm/s
Here you can set the feed rate
of the ECG curve display and
so change the time
resolution.
50 mm/s
Duration -
5 s
10 s
Here you can set the
recording duration of the
12-lead ECG.
5 s
View -
Classic
Cabrera
Here you can set the
sequence in which the leads
are displayed in the 12-lead
ECG.
Classic
Electrode
marking
-
ERC
AHA
Here you can set whether the
positions of the ECG
electrodes in 12-lead ECG
function mode are named in
accordance with European
(ERC) or American (AHA)
coding and the colors
assigned accordingly.
ERC
Age - 0 to 99 years
Here you can set the patient’s
age.
50
