40 EN MEDUCORE Standard
2
WM 68401 04/2021
3 Description
6 Patient group
Displays the selected patient group:
•Adult
•Child
7 Mode indicator Indicates the mode currently selected.
8 Alarm limits Displays the set alarm limits.
9 Alarm off indicator
Indicates whether alarm output is deactivated in AED
mode.
10 AED instructions Give instructions on carrying out CPR.
11 Analysis
• Allows you to start a cardiac rhythm analysis
manually.
• Only displayed if Start analysis automatically is
deactivated in the operator menu (see “13.3 AED
settings”, page 310).
12 Monitor mode Provides access to monitor mode.
13
Manual mode (only with Manual
defibrillation option)
Provides access to manual mode.
14 ECG calibration mark
Displays the section corresponding to 1 mV of the ECG
signal.
15 NIBP Displays blood pressure.
16 Pulse Displays pulse rate.
17 SpO
2
Displays oxygen saturation.
18 Center curve field Displays the plethysmogram.
19 HR Displays heart rate.
20 Top curve field Displays the ECG lead (Pad, II).
21 Upload symbol
• Indicates that e-mail delivery 12-lead ECG has
been started (only with E-mail delivery 12-lead
ECG option).
• Indicates whether the last e-mail delivery started
was successful (only with E-mail delivery 12-lead
ECG option).
• Indicates whether the function check has been
uploaded to WEINMANN Connect successfully.
• Indicates whether the session data have been
uploaded to WEINMANN Connect successfully
(only with Upload session data option).
• Indicates whether the service data have been
uploaded to WEINMANN Emergency successfully.
22 Printer symbol (only with Printing option)
Indicates whether the printer is connected to the
device.
No. Designation Description
