WM 68401 04/2021
MEDUCORE Standard
2
EN 53
3 Description
6 Date Displays the date on which the session took place.
7 Time Displays the time at which the session began.
8 Events Displays events during a session.
9 Monitor mode
• Provides access to monitor mode.
• Depending on the mode from which the session
archive was opened, other function buttons may
be possible.
10 Recording point
Displays the exact time at which a momentary
recording in an event took place.
11 Scroll bar
Indicates how far time was fast-forwarded within an
event.
12 NIBP Displays blood pressure at the time of recording.
13 SpO
2
Displays oxygen saturation at the time of recording.
14 Bottom curve field
Displays the selected ECG lead or plethysmogram at
the time of recording:
• I, II, III, aVR, aVL or aVF
• ECG lead via the defibrillation electrodes/paddles
(Pad, II)
15 Curve
Allows you to select the ECG lead or plethysmogram
at the time of recording.
16 Amplitude scaling
Allows you to set the amplification of the ECG signal
and thus the height of the ECG curve.
17 Feed rate
Allows you to set the feed rate of the ECG curve
display and so change the time resolution.
18 Pulse Displays pulse rate at the time of recording.
19 HR Displays heart rate at the time of recording.
20 Scroll speed Allows you to select the resolution of scrolling.
21 NIBP Displays current blood pressure.
22 Pulse Displays current pulse rate.
23 SpO
2
Displays current oxygen saturation.
24 HR Displays current heart rate.
25 Session ID: Displays the session ID.
26 Time: Displays the time at which the session began.
27 Date: Displays the date on which the session took place.
28 Session archive Displays a list of all the device sessions.
No. Designation Description
