February 2013
3-84
ColorQube® 9303 Family
TP 2 to TP 10
Image Quality
TP 2 to TP 10 Solid Fill Test Pages
Solid fills are used to purge the jets of contamination or to correct cross-colour contaminated
jets. Solid fills are also used to examine media damage, cleaning unit function, skew, and mar
-
gins.
Solid fill test pages are printed from dC612. TP5 black solid fill can also be printed from dC959.
NOTE: All test prints should be printed on A4 or 8.5 x 11 inch plain paper and long edge feed.
Use the best quality media available. Do not use hole punched paper.
NOTE: When printing TP 5 from dC959, ensure that the paper is loaded LEF into tray 4.
Purpose
Figure 1. These single-sided prints provide solid-fills in all eight colours:.
• Select TP 2 to print two cyan solid fills
• Select TP 3 to print two magenta solid fills
• Select TP 4 to print two yellow solid fills
• Select TP 5 to print two black solid fills
• Select TP 6 to print two red solid fills
• Select TP 7 to print two green solid fills
• Select TP 8 to print two blue solid fills
• Select TP 9 to print two white solid fills
• Select TP 10 to print a single set of all eight solid fills (cyan, magenta, yellow, black, red,
green, blue and white).
To solve image quality problems associated with solid fills, refer to IQ 5, IQ 9, IQ 10 and IQ 24.
Figure 1 Solid fill pages
TP 3 Magenta solid fill
TP 4 Yellow solid fill
TP 9 White solid fill
P 8 Blue solid fill
P 7 Green solid fill
P 6 Red solid fill
TP 5 Black
solid fill
