February 2013
4-81
ColorQube® 9303 Family
REP 10.13, REP 10.14
Repairs/Adjustments
5. Remove the exit / duplex solenoid from the diverter gate assembly, Figure 4.
Figure 4 Remove exit / duplex solenoid
Replacement
Replacement is the reverse of the removal procedure.
REP 10.14 Exit Motor (M5)
Parts List on PL 10.15 Item 11
Removal
WARNING
Switch off the electricity to the machine. Refer to GP 14. Disconnect the power cord
from the customer supply while performing tasks that do not need electricity. Electricity
can cause death or injury. Moving parts can cause injury.
WARNING
Take care during this procedure. Sharp edges may be present that can cause injury.
1. Remove the exit paper path, REP 10.20.
2. Remove the drive gears, Figure 1.
Figure 1 Gear removal
1
Remove 2 screws release the sole-
noid from the diverter guide.
1
Remove 2 gears then 2 drive belts.
To Next Page
