Xerox ColorQube 9301 Service Manual

February 2013
4-80
ColorQube® 9303 Family
REP 10.13
Repairs/Adjustments
3. Remove the ground lead, Figure 2.
Figure 2 Ground screw removal
4. Remove the diverter gate from the top exit baffle, Figure 3.
Figure 3 Release the diverter gate
1
Remove the screw and ground
lead.
1
Slide to release the guide
2
Carefully release the tab.
