Xerox ColorQube 9301

February 2013
5-65
ColorQube® 9303 Family
PL 31.10
Parts Lists
PL 31.10 Maintenance/Installation/
Removal Kits (1 of 3)
Item Part Description
1 – Fax adapter kit (see below for
variants)
– 604K67590 United Kingdom, Ireland, Spain,
Portugal, Greece
– 604K67600 France, Netherlands, Belgium
– 604K67610 Germany, Austria, Italy, Switzerland
– 604K67620 Sweden, Norway, Finland,
Denmark
– 604K73110 Australia, New Zealand, Hong
Kong, Singapore
2 497K07760 Foreign device interface kit
3 130K75900 HVF Low level sensor - spares
pack
4 604K73050 LCSS paddle spares kit
5 – Hole punch kit (see below for
variants)
– 604K55160 2 hole punch kit (XE)
– 604K55190 2 hole punch kit (legal) (XE)
– 604K55170 3 hole punch kit (USSG/XCL)
– 498K14041 3 hole punch kit (XE)
– 604K55200 4 hole punch kit (Sweden)
– 604K55180 4 hole punch kit (XE)
6 – USB print connectivity kit (Not
spared)
7 – Finishing devices (variants below)
– – LCSS (no hole punch) (Not spared)
– – LCSS (no hole punch) (Not spared)
(30 ppm)
8 – Tray 5 (Not spared)
9 498K12130 Tray 5 paper feed kit (A3 SEF
option) (Not spared)
10 498K12150 Tray 5 paper feed kit (A4 SEF
option) (Not spared)
11 604K48370 CVT Roll KIt
12 604K61780 GUI gasket kit
13 498K17780 Generic installation request kit (XE)
14 604K54972 Umbilical kit
15 604K67570 Feedhead assembly kit (REP 5.3)
NOTE: 498K part numbers should not be ordered by the
CSE. 498K part numbers are customer install kits and are
shown for reference only.
