Phaser 3250 Laser Printer Service Manual 8-31
Service Parts Disassembly
Replacement Note
1. Ensure that there are no wiring harnesses sitting in the clip area.
2. Ensure the metal plate is seated behind the plastic tab of the Top Cover.
s3250-084
s3250-085
Metal Plate
