GENERAL CHASSIS
4-19
Removing the T-bar
Order Job/Parts to remove Q’ty Remarks
Rider seat Refer to “Removing the seats and covers”.
Fuel tank Refer to “FUEL TANK” on page 7-1.
1T-bar 1
2 Heat protector 1
For installation, reverse the removal proce-
dure.
1
2
37 Nm (3.7 m
•
kg, 27 ft
•
Ib)
T
.R.
37 Nm (3.7 m
•
kg, 27 ft
•
Ib)
T
.R.
