SIGNALING SYSTEM
8-23
EAS27290
TROUBLESHOOTING
• Any of the following fail to light: turn signal light, brake light or indicator light.
• The horn fails to sound.
• The fuel meter fails to come on.
• The speedometer fails to operate.
TIP
• Before troubleshooting, remove the following part(s):
1. Side cowlings
2. Front cowling assembly
3. Fuel tank
4. T-bar
5. Left side cover
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
1. Check the fuses.
(Main, ignition, signaling system,
hazard lighting, backup, fuel injec-
tion system, brake light, and ABS
ECU)
Refer to “CHECKING THE FUS-
ES” on page 8-173.
Replace the fuse(s).
2. Check the battery.
Refer to “CHECKING AND
CHARGING THE BATTERY” on
page 8-174.
• Clean the battery terminals.
• Recharge or replace the battery.
3. Check the main switch.
Refer to “CHECKING THE
SWITCHES” on page 8-169.
Replace the main switch/immobilizer unit.
4. Check the entire signaling system
wiring.
Refer to “CIRCUIT DIAGRAM” on
page 8-21.
Properly connect or replace the wire har-
ness.
Check the condition of each of the sig-
naling system circuits. Refer to
“Checking the signaling system”.
