WINDSHIELD DRIVE SYSTEM
8-109
EAS27630
TROUBLESHOOTING
The windshield fails to move.
TIP
• Before troubleshooting, remove the following part(s):
1. Front cowling assembly
2. Fuel tank
3. T-bar
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
1. Check that there are no rocks or
other foreign material in the wind-
shield drive unit side rails.
Remove the foreign material.
2. Check that there is no foreign mate-
rial between the cable and the pul-
ley.
Remove the foreign material.
3. Check the fuses.
(Main, ignition, signaling system,
backup and windshield drive sys-
tem)
Refer to “CHECKING THE FUS-
ES” on page 8-173.
Replace the fuse(s).
4. Check the battery.
Refer to “CHECKING AND
CHARGING THE BATTERY” on
page 8-174.
• Clean the battery terminals.
• Recharge or replace the battery.
5. Check the main switch.
Refer to “CHECKING THE
SWITCHES” on page 8-169.
Replace the main switch/immobilizer unit.
6. Check the menu switch.
Refer to “CHECKING THE
SWITCHES” on page 8-169.
• The menu switch is faulty.
• Replace the left handlebar switch.
7. Check the select switch.
Refer to “CHECKING THE
SWITCHES” on page 8-169.
• The select switch is faulty.
• Replace the left handlebar switch.
