WINDSHIELD DRIVE SYSTEM
8-110
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
8. Check the windshield drive unit re-
lay (up).
Refer to “CHECKING THE RE-
LAYS” on page 8-177.
Replace the windshield drive unit relay
(up).
9. Check the windshield drive unit re-
lay (down).
Refer to “CHECKING THE RE-
LAYS” on page 8-177.
Replace the windshield drive unit relay
(down).
10.Check the windshield drive motor.
Refer to “CHECKING THE WIND-
SHIELD DRIVE UNIT” on page
8-192.
Replace the windshield drive unit.
11.Check the entire windshield drive
system wiring.
Refer to “CIRCUIT DIAGRAM” on
page 8-107.
Properly connect or replace the wire har-
ness.
Replace the meter assembly.
