ACCESSORY BOX SYSTEM
8-113
ET3P61012
TROUBLESHOOTING
The accessory box fails to operate.
TIP
• Before troubleshooting, remove the following part(s):
1. Right upper inner panel
2. Left side cowling
3. Fuel tank
4. T-bar
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
1. Check the fuses.
(Main and signaling system)
Refer to “CHECKING THE FUS-
ES” on page 8-173.
Replace the fuse(s).
2. Check the battery.
Refer to “CHECKING AND
CHARGING THE BATTERY” on
page 8-174.
• Clean the battery terminals.
• Recharge or replace the battery.
3. Check the main switch.
Refer to “CHECKING THE
SWITCHES” on page 8-169.
Replace the main switch/immobilizer unit.
4. Check the accessory box solenoid.
Refer to “CHECKING THE ACCES-
SORY BOX SOLENOID” on page
8-192.
Replace the accessory box solenoid.
5. Check the entire accessory box
system wiring.
Refer to “CIRCUIT DIAGRAM” on
page 8-111.
Properly connect or replace the wire har-
ness.
This accessory box system circuit is
OK.
