Yamaha FJR1300A - Page 171

FRONT WHEEL
4-14
Disassembling the front wheel
Order Job/Parts to remove Q’ty Remarks
1 Oil seal 2
2 Wheel bearing 2
3 Spacer 1
For assembly, reverse the disassembly pro-
cedure.
