ENGINE REMOVAL
5-1
EAS23710
ENGINE REMOVAL
Removing the exhaust pipe assembly
Order Job/Parts to remove Q’ty Remarks
Left side cowling/Right side cowling/T-bar
Refer to “GENERAL CHASSIS” on page
4-1.
Fuel tank Refer to “FUEL TANK” on page 7-1.
Coolant
Drain.
Refer to “CHANGING THE COOLANT” on
page 3-19.
Radiator Refer to “RADIATOR” on page 6-1.
1
O
2
sensor coupler
1 Disconnect.
2
O
2
sensor
1
3 Left muffler 1
4 Right muffler 1
5 Exhaust pipe assembly 1
6Gasket 4
For installation, reverse the removal proce-
dure.
T
R
.
.
20 Nm (2.0 m
•
kg, 14 ft
•
Ib)
T
R
.
.
45 Nm (4.5 m
•
kg, 32 ft
•
Ib)
T
R
.
.
20 Nm (2.0 m
•
kg, 14 ft
•
Ib)
T
R
.
.
17 Nm (1.7 m
•
kg, 12 ft
•
Ib)
T
R
.
.
12 Nm (1.2 m
•
kg, 8.7 ft
•
Ib)
5
6
2
(8)
3
1
4
New
T
R
.
.
25 Nm (2.5 m
•
kg, 18 ft
•
Ib)
To Next Page
