OIL COOLER
6-5
EAS26420
CHECKING THE OIL COOLER
1. Check:
• Oil cooler
Cracks/damage → Replace.
2. Check:
• Oil cooler inlet hose
• Oil cooler outlet hose
• Water pump outlet hose
• Water pump outlet pipe
• Water jacket joint inlet hose
Cracks/damage/wear → Replace.
EAS26430
INSTALLING THE OIL COOLER
1. Clean:
• Mating surfaces of the oil cooler and the
crankcase
(with a cloth dampened with lacquer thinner)
2. Install:
• O-ring
• Oil cooler
NOTE:
Make sure the O-ring is positioned properly.
3. Fill:
• Cooling system
(with the specified amount of the recom-
mended coolant)
Refer to “CHANGING THE COOLANT” on
page 3-19.
• Crankcase
(with the specified amount of the recom-
mended engine oil)
Refer to “CHANGING THE ENGINE OIL” on
page 3-13.
4. Check:
• Cooling system
Leaks → Repair or replace any faulty part.
5. Measure:
• Radiator cap opening pressure
Below the specified pressure → Replace the
radiator cap.
Refer to “CHECKING THE RADIATOR” on
page 6-3.
T
R
.
.
Oil cooler bolt
12 Nm (1.2 m·kg, 8.7 ft·lb)
LOCTITE
®
New
