Yamaha FJR1300A - Handlebars

HANDLEBARS
4-60
EAS22850
HANDLEBARS
Removing the left handlebar
Order Job/Parts to remove Q’ty Remarks
1 Clutch switch coupler 1 Disconnect.
2 Clutch master cylinder holder 1
3 Clutch master cylinder assembly 1
4 Left handlebar 1
5 Lead holder 1
6 Left handlebar switch 1
7 Grip end 1
8 Handlebar grip 1
For installation, reverse the removal proce-
dure.
