Yamaha FJR1300A - Page 218

HANDLEBARS
4-61
Removing the right handlebar
Order Job/Parts to remove Q’ty Remarks
1 Front brake light switch connector 2 Disconnect.
2 Front brake master cylinder holder 1
3 Front brake master cylinder assembly 1
4 Grip end 1
5 Throttle cable housing 2
6 Throttle cable 2 Disconnect.
7 Throttle grip 1
8 Right handlebar 1
9 Lead holder 1
10 Right handlebar switch 1
For installation, reverse the removal proce-
dure.
