Yamaha FJR1300A - Shaft Drive

SHAFT DRIVE
4-87
EAS23550
SHAFT DRIVE
Removing the final drive assembly
Order Job/Parts to remove Q’ty Remarks
Final gear oil
Drain.
Refer to “CHANGING THE ENGINE OIL” on
page 3-13.
Rear wheel Refer to “REAR WHEEL” on page 4-20.
1 Final drive assembly 1
For installation, reverse the removal proce-
dure.
