Yamaha FJR1300A - Page 243

SWINGARM
4-86
3. Tighten:
• Pivot shaft
• Pivot shaft locknut
• Pivot shaft nut
3. Swingarm
4. Connecting arm
A. Left side
B. Right side
T
R
.
.
Pivot shaft
23 Nm (2.3 m·kg, 17 ft·lb)
T
R
.
.
Pivot shaft locknut
115 Nm (11.5 m·kg, 85 ft·lb)
T
R
.
.
Pivot shaft nut
125 Nm (12.5 m·kg, 90 ft·lb)
1
3
a
A
3
2
b
2
A
B
b
4
4
