ELECTRICAL SPECIFICATIONS
2-12
EAS20310
ELECTRICAL SPECIFICATIONS
Voltage
System voltage 12 V
Ignition system
Ignition system Transistorized coil ignition (digital)
Ignition timing (B.T.D.C.) 5.0°/1050 r/min
Engine control unit
Model/manufacturer FUA0008/MITSUBISHI (Europe except (B) and
(F)) (ZA) (AUS)
FUA0009/MITSUBISHI (B) (F)
Ignition coil
Model/manufacturer JO383/DENSO
Minimum ignition spark gap 6.0 mm (0.24 in)
Primary coil resistance 1.53–2.07 Ω at 20 °C (68 °F)
Secondary coil resistance 12–18 kΩ at 20 °C (68 °F)
Spark plug cap
Material Resin
Resistance 10.0 kΩ
AC magneto
Model/manufacturer LNX07/DENSO
Standard output 14.0 V 590 W 5000 r/min
Stator coil resistance 0.13–0.19 Ω at 20 °C (68 °F)
Voltage regulator
Rectifier/regulator
Regulator type Semi conductor-short circuit
Model/manufacturer FH012AA/SHINDENGEN
Regulated voltage (DC) 14.2–14.8 V
Rectifier capacity (DC) 50.0 A
Withstand voltage 40.0 V
Battery
Model GT14B-4
Voltage, capacity 12 V, 12.0 Ah
Manufacturer GS YUASA
Ten hour rate amperage 1.20 A
Headlight
Bulb type Halogen bulb
Bulb voltage, wattage × quantity
Headlight 12 V, 60 W/55.0 W × 2
Auxiliary light 12 V, 5.0 W × 2
Tail/brake light 12 V, 5.0 W/21.0 W × 2
Front turn signal light 12 V, 21.0 W × 2
Rear turn signal light 12 V, 21.0 W × 2
