ELECTRICAL SPECIFICATIONS
2-13
License plate light 12 V, 5.0 W × 1
Meter lighting LED
Indicator light
Neutral indicator light LED
Turn signal indicator light LED
Oil level warning light LED
High beam indicator light LED
Engine trouble warning light LED
ABS warning light LED
Immobilizer system indicator light LED
Electric starting system
System type Constant mesh
Starter motor
Model/manufacturer 3P6/YAMAHA
Power output 0.80 kW
Armature coil resistance 0.024–0.030 Ω at 20 °C (68 °F)
Brush overall length 10.8 mm (0.43 in)
Limit 3.65 mm (0.14 in)
Brush spring force 5.28–7.92 N (19.01–28.51 oz) (538–808 gf)
Commutator diameter 24.5 mm (0.96 in)
Limit 23.5 mm (0.93 in)
Mica undercut (depth) 1.50 mm (0.06 in)
Starter relay
Model/manufacturer MS5F-631/JIDECO
Amperage 180.0 A
Horn
Horn type Plane
Quantity 2 pcs
Model/manufacturer HF-12/NIKKO
Maximum amperage 3.0 A
Coil resistance 1.01–1.11 Ω at 20 °C (68 °F)
Performance 108–116 dB/2 m (6.6 ft)
Turn signal/hazard relay
Relay type Full transistor
Model/manufacturer FE246BH/DENSO
Built-in, self-canceling device No
Turn signal blinking frequency 75.0–95.0 cycles/min
Wattage 21 W × 2.0
Oil level switch
Model/manufacturer 3P6/DENSO
Fuel gauge
Model/manufacturer 5JW/DENSO
Sender unit resistance (full) 19.0–21.0 Ω
Sender unit resistance (empty) 139.0–141.0 Ω
