CRANKCASE
5-74
EAS25540
CRANKCASE
Separating the crankcase
Order Job/Parts to remove Q’ty Remarks
Engine Refer to “ENGINE REMOVAL” on page 5-1.
Cylinder head Refer to “CYLINDER HEAD” on page 5-18.
Starter clutch
Refer to “GENERATOR AND STARTER
CLUTCH” on page 5-28.
Pickup rotor Refer to “PICKUP ROTOR” on page 5-34.
Oil pump Refer to “OIL PUMP” on page 5-58.
Middle drive shaft assembly Refer to “MIDDLE GEAR” on page 5-63.
Clutch housing Refer to “CLUTCH” on page 5-41.
1 Timing chain 1
2 Oil pump drive chain guide 1
3 Oil pump drive chain 1
4 Oil pump drive sprocket 1
5 Spacer 1
6Collar 1
7 Spring washer 1
8 Gear position switch 1
T
R
.
.
24 Nm (2.4 m
•
kg, 17 ft
•
Ib)
T
R
.
.
12 Nm (1.2 m
•
kg, 8.7 ft
•
Ib)
T
R
.
.
12 Nm (1.2 m
•
kg, 8.7 ft
•
Ib)
T
R
.
.
1st 20 Nm (2.0 m
•
kg, 14 ft
•
lb)
2nd 20 Nm (2.0 m
•
kg, 14 ft
•
lb)
Final Specified angle 115–125˚
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
LT
New
LS
T
R
.
.
4 Nm (0.4 m
•
kg, 2.9 ft
•
Ib)
E
E
E
E
E
E
E
E
LT
LT
8
10
10
7
6
5
4
1
2
3
10
9
(4)
(10)
(10)
(2)
(2)
To Next Page
