Yamaha FJR1300A - Balancers

BALANCERS
5-103
ET3P61031
BALANCERS
Removing the front balancer
Order Job/Parts to remove Q’ty Remarks
Crankcase
Separate.
Refer to “CRANKCASE” on page 5-74.
1 Front balancer lever 1
2 Front balancer shaft 1
3Washer 2
4 Bearing 2
5 Front balancer gear 1
6 Damper 4
7 Front balancer weight 1
For installation, reverse the removal proce-
dure.
