TRANSMISSION
5-102
NOTE:
• The bearing pin “1” must face towards the rear
of the upper crankcase.
• Make sure the bearing circlip “2” is inserted into
the groove in the upper crankcase.
5. Check:
• Transmission
Rough movement → Repair.
NOTE:
Oil each gear, shaft, and bearing thoroughly.
1
2
