Yamaha FJR1300A - Radiator

RADIATOR
6-1
EAS26380
RADIATOR
Removing the radiator
Order Job/Parts to remove Q’ty Remarks
Coolant
Drain.
Refer to “CHANGING THE COOLANT” on
page 3-19.
Throttle bodies Refer to “THROTTLE BODIES” on page 7-4.
1 Radiator cap 1
2 Coolant reservoir hose 1
3 Coolant reservoir breather hose 1
4 Coolant reservoir cap 1
5 Coolant reservoir 1
6 Radiator inlet hose 1
7 Plunger control unit hose 2 1
8 Oil cooler outlet hose 1
9 Left horn (low) 1
10 Coolant reservoir bracket 1
11 Water pump breather hose 1
12 Radiator outlet hose 1
13 Right horn (high) 1
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
T
R
.
.
12 Nm (1.2 m
•
kg, 8.7 ft
•
Ib)
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
LT
LT
LT
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
1
2
4
5
6
7
8
3
9
10
11
13
14
15
21
16
17
18
19
20
12
