REAR SHOCK ABSORBER ASSEMBLY
4-79
EAS23160
REAR SHOCK ABSORBER ASSEMBLY
Removing the rear shock absorber assembly
Order Job/Parts to remove Q’ty Remarks
Air filter case
Refer to “GENERAL CHASSIS” on page
4-1.
Rear wheel Refer to “REAR WHEEL” on page 4-20.
Mufflers/Exhaust pipe assembly Refer to “ENGINE REMOVAL” on page 5-1.
1 Rectifier/regulator coupler 1 Disconnect.
2 Stator coil coupler 1 Disconnect.
3
Rear shock absorber spring preload adjusting
lever nut
3
4
Rear shock absorber assembly lower nut/Wash-
er/Bolt
1/1/1
5 Connecting arm nut/Washer/Bolt 2/2/2
6 Connecting arm 2
7
Rear shock absorber assembly upper
nut/Bolt/Spacer
1/1/1
8 Rear shock absorber assembly 1
9 Centerstand 1
10 Relay arm nut/Bolt/Spacer 1/1/1
New
New
New
New
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
T
R
.
.
40 Nm (4.0 m
•
kg, 29 ft
•
Ib)
T
R
.
.
48 Nm (4.8 m
•
kg, 35 ft
•
Ib)
5
T
R
.
.
64 Nm (6.4 m
•
kg, 46 ft
•
Ib)
T
R
.
.
40 Nm (4.0 m
•
kg, 29 ft
•
Ib)
7
7
10
3
10
1
2
LS
LS
8
13
15
12
17
15
15
15
5
6
16
16
15
14
17
11
5
5
6
15
4
4
9
LS
T
R
.
.
55 Nm (5.5 m
•
kg, 40 ft
•
Ib)
