BALANCERS
5-104
Removing the rear balancer
Order Job/Parts to remove Q’ty Remarks
Throttle bodies Refer to “THROTTLE BODIES” on page 7-4.
Pickup rotor cover Refer to “PICKUP ROTOR” on page 5-34.
Clutch cover Refer to “CLUTCH” on page 5-41.
1 Rear balancer cover 1
2 Rear balancer cover gasket 1
3 Rear balancer lever 1
4 Rear balancer shaft 1
5Washer 2
6 Bearing 2
7 Rear balancer gear 1
8 Damper 4
9 Rear balancer weight 1
For installation, reverse the removal proce-
dure.
