SHAFT DRIVE
4-88
Removing the universal joint
Order Job/Parts to remove Q’ty Remarks
1 Shift arm 1
2 Left footrest assembly 1
3 Sidestand switch coupler 1 Disconnect.
4 Sidestand 1
5 Drive shaft dust cover 1
6 Universal joint dust cover 1
7 Universal joint 1
For installation, reverse the removal proce-
dure.
