Yamaha FJR1300A - Page 197

REAR BRAKE
4-40
* Apply silicon grease
Disassembling the rear brake master cylinder
Order Job/Parts to remove Q’ty Remarks
1 Dust boot 1
2 Circlip 1
3 Brake master cylinder push rod 1
4 Brake master cylinder kit 1
5 Brake master cylinder body 1
For assembly, reverse the disassembly pro-
cedure.
