CLUTCH
5-41
EAS25060
CLUTCH
Removing the clutch cover
Order Job/Parts to remove Q’ty Remarks
Right side cowling
Refer to “GENERAL CHASSIS” on page
4-1.
Engine oil
Drain.
Refer to “CHANGING THE ENGINE OIL” on
page 3-13.
1 Clutch cover 1
2 Clutch cover gasket 1
3 Dowel pin 2
4 Damper cover 1
5 Damper 1
For installation, reverse the removal proce-
dure.
LT
3
4
5
2
1
(10)
(5)
3
New
T
R
.
.
12 Nm (1.2 m
•
kg, 8.7 ft
•
Ib)
T
R
.
.
12 Nm (1.2 m
•
kg, 8.7 ft
•
Ib)
T
R
.
.
12 Nm (1.2 m
•
kg, 8.7 ft
•
Ib)
