FEATURES
1-26
Coolant temperature meter
With the key in the “ON” position, the coolant
temperature meter indicates the temperature of
the coolant. When the key is turned to “ON”, all
of the display segments of the coolant tempera-
ture meter will appear one after the other and
then disappear in order to test the electrical cir-
cuit. The coolant temperature varies with chang-
es in the weather and engine load. If the top
segment flashes, stop the vehicle and let the en-
gine cool.
CAUTION:
EC3P61040
Do not operate the engine if it is overheated.
Transmission gear display
This display shows the selected gear. The neu-
tral position, however, is not displayed, it is indi-
cated by the neutral indicator light.
Ambient temperature, instantaneous fuel
consumption and average fuel consumption
modes (except for the UK)
Push the “RESET” button to switch the display
between the ambient temperature mode and the
fuel consumption modes in the following order:
Air (ambient temperature) → km/L or L/100 km
(instantaneous fuel consumption) → AV_ _ km/L
or AV_ _ L/100 km (average fuel consumption)
→ Air (ambient temperature)
Ambient temperature mode
This display shows the ambient temperature
from -9 °C to 50 °C in 1 °C increments. The tem-
perature displayed may vary from the ambient
temperature.
NOTE:
1.
• If the ambient temperature falls below -9 °C, a
lower temperature than -9 °C will not be dis-
played.
• If the ambient temperature climbs above 50 °C,
a higher temperature than 50 °C will not be dis-
played.
• The accuracy of the temperature reading may
be affected when riding slowly (approximately
under 20 km/h) or when stopped at traffic sig-
nals, railroad crossings, etc.
1. Coolant temperature meter
1. Transmission gear display
2. Neutral indicator light “”
1. Ambient temperature/instantaneous fuel
consumption/average fuel consumption
2. “SELECT” button
3. “RESET” button
1. Ambient temperature
