IGNITION SYSTEM
8-7
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
8. Check the main switch.
Refer to “CHECKING THE
SWITCHES” on page 8-149.
Replace the main switch/immobilizer unit.
9. Check the engine stop switch.
Refer to “CHECKING THE
SWITCHES” on page 8-149.
Replace the right handlebar switch.
10.Check the gear position switch.
Refer to “CHECKING THE
SWITCHES” on page 8-149.
Replace the gear position switch.
11.Check the sidestand switch.
Refer to “CHECKING THE
SWITCHES” on page 8-149.
Replace the sidestand switch.
12.Check the relay unit (diode).
Refer to “CHECKING THE RELAY
UNIT (DIODE)” on page 8-160.
Replace the relay unit.
13.Check the lean angle sensor.
Refer to “CHECKING THE LEAN
ANGLE SENSOR” on page 8-163.
Replace the lean angle sensor.
14.Check the entire ignition system
wiring.
Refer to “CIRCUIT DIAGRAM (1/2)”
on page 8-1 and “CIRCUIT DIA-
GRAM (2/2)” on page 8-3.
Properly connect or repair the ignition sys-
tem wiring.
Replace the ECU.
