ELECTRIC STARTING SYSTEM
8-15
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
8. Check the main switch.
Refer to “CHECKING THE
SWITCHES” on page 8-149.
Replace the main switch/immobilizer unit.
9. Check the engine stop switch.
Refer to “CHECKING THE
SWITCHES” on page 8-149.
Replace the right handlebar switch.
10.Check the gear position switch.
Refer to “CHECKING THE
SWITCHES” on page 8-149.
Replace the gear position switch.
11.Check the sidestand switch.
Refer to “CHECKING THE
SWITCHES” on page 8-149.
Replace the sidestand switch.
12.Check the clutch switch.
Refer to “CHECKING THE
SWITCHES” on page 8-149.
Replace the clutch switch.
13.Check the start switch.
Refer to “CHECKING THE
SWITCHES” on page 8-149.
Replace the right handlebar switch.
14.Check the entire starting system
wiring.
Refer to “CIRCUIT DIAGRAM (1/2)”
on page 8-9 and “CIRCUIT DIA-
GRAM (2/2)” on page 8-11.
Properly connect or repair the starting sys-
tem wiring.
The starting system circuit is OK.
