LIGHTING SYSTEM
8-25
EAS27260
TROUBLESHOOTING
Any of the following fail to light: headlights, high beam indicator light, taillight, license plate light, auxiliary
lights or meter light.
NOTE:
• Before troubleshooting, remove the following part(s):
1. Front cowling assembly
2. Fuel tank
3. T-bar
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
1. Check the condition of each bulb
and bulb socket.
Refer to “CHECKING THE BULBS
AND BULB SOCKETS” on page
8-152.
Replace the bulb(s) and bulb socket(s).
2. Check the fuses.
(Main, headlights, ignition, and haz-
ard lighting)
Refer to “CHECKING THE FUS-
ES” on page 8-153.
Replace the fuse(s).
3. Check the battery.
Refer to “CHECKING AND
CHARGING THE BATTERY” on
page 8-154.
• Clean the battery terminals.
• Recharge or replace the battery.
4. Check the main switch.
Refer to “CHECKING THE
SWITCHES” on page 8-149.
Replace the main switch/immobilizer unit.
5. Check the dimmer switch.
Refer to “CHECKING THE
SWITCHES” on page 8-149.
Replace the left handlebar switch.
6. Check the pass switch.
Refer to “CHECKING THE
SWITCHES” on page 8-149.
Replace the left handlebar switch.
7. Check the headlight relay (on/off).
Refer to “CHECKING THE RE-
LAYS” on page 8-157.
Replace the headlight relay (on/off).
To Next Page
