FUEL INJECTION SYSTEM
8-66
Fault code No. 30 Symptom Latch up detected.
No normal signal is received from the lean angle sensor.
Diagnostic code No. 08 Lean angle sensor
Order Item/components and probable
cause
Check or maintenance job Reinstatement
method
1 The vehicle has overturned. Raise the vehicle upright. Turning the
main switch to
“ON” (however,
the engine can-
not be restarted
unless the main
switch is first
turned “OFF”).
2 Installed condition of lean angle sen-
sor
Check the installed direction and
condition of the sensor.
3 Connections
• Lean angle sensor coupler
• Wire harness ECU coupler
• Check the coupler for any pins
that may be pulled out.
• Check the locking condition of
the coupler.
• If there is a malfunction, repair it
and connect the coupler se-
curely.
4 Defective lean angle sensor • Execute the diagnostic mode.
(Code No.08)
• Replace if defective.
Refer to “CHECKING THE
LEAN ANGLE SENSOR” on
page 8-163.
To Next Page
