WINDSHIELD DRIVE SYSTEM
8-91
EAS27630
TROUBLESHOOTING
The windshield fails to operate.
NOTE:
• Before troubleshooting, remove the following part(s):
1. Front cowling assembly
2. Fuel tank
3. T-bar
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
1. Check the fuses.
(Main, signaling system, and back-
up)
Refer to “CHECKING THE FUS-
ES” on page 8-153.
Replace the fuse(s).
2. Check the battery.
Refer to “CHECKING AND
CHARGING THE BATTERY” on
page 8-154.
• Clean the battery terminals.
• Recharge or replace the battery.
3. Check the main switch.
Refer to “CHECKING THE
SWITCHES” on page 8-149.
Replace the main switch/immobilizer unit.
4. Check the windshield position
switch.
Refer to “CHECKING THE
SWITCHES” on page 8-149.
Replace the left handlebar switch.
5. Check the entire windshield drive
system wiring.
Refer to “CIRCUIT DIAGRAM (1/2)”
on page 8-87 and “CIRCUIT DIA-
GRAM (2/2)” on page 8-89.
Properly connect or repair the windshield
drive system wiring.
Replace the windshield drive unit.
