CHASSIS SPECIFICATIONS
2-10
Front disc brake
Disc outside diameter × thickness 320.0 × 4.5 mm (12.60 × 0.18 in)
Brake disc thickness limit 4.0 mm (0.16 in)
Brake disc deflection limit 0.10 mm (0.0039 in)
Brake pad lining thickness (inner) 5.5 mm (0.22 in)
Limit 0.5 mm (0.02 in)
Brake pad lining thickness (outer) 5.5 mm (0.22 in)
Limit 0.5 mm (0.02 in)
Master cylinder inside diameter 15.00 mm (0.59 in)
Caliper cylinder inside diameter 30.23 mm × 4 (1.19 in × 4)
Caliper cylinder inside diameter (for unified brake)33.96 mm × 2, 22.65 mm × 2 (1.34 in × 2, 0.89 in
× 2)
Recommended fluid DOT 4
Rear brake
Type Single disc brake
Operation Right foot operation
Brake pedal position 42.0 mm (1.65 in) (below the top of the rider
footrest)
Rear disc brake
Disc outside diameter × thickness 282.0 × 5.0 mm (11.10 × 0.20 in)
Brake disc thickness limit 4.5 mm (0.18 in)
Brake disc deflection limit 0.15 mm (0.0059 in)
Brake pad lining thickness (inner) 6.3 mm (0.25 in)
Limit 0.8 mm (0.03 in)
Brake pad lining thickness (outer) 6.3 mm (0.25 in)
Limit 0.8 mm (0.03 in)
Master cylinder inside diameter 15.0 mm (0.59 in)
Caliper cylinder inside diameter 41.30 mm (1.63 in)
Recommended fluid DOT 4
Clutch
Recommended fluid DOT 4
Master cylinder inside diameter 14.0 mm (0.55 in)
Release cylinder inside diameter 29.6 mm (1.17 in)
Steering
Steering bearing type Angular bearing
Lock to lock angle (left) 34.0°
Lock to lock angle (right) 34.0°
Front suspension
Type Telescopic fork
Spring/shock absorber type Coil spring/oil damper
Front fork travel 135.0 mm (5.31 in)
Fork spring free length 262.0 mm (10.31 in)
Limit 257.0 mm (10.12 in)
Collar length 149.5 mm (5.89 in)
Installed length 251.0 mm (9.88 in)
Spring rate K1 8.30 N/mm (47.39 lb/in) (0.85 kgf/mm)
Spring stroke K1 0.0–135.0 mm (0.00–5.31 in)
Inner tube outer diameter 48.0 mm (1.89 in)
Inner tube bending limit 0.2 mm (0.01 in)
