TIGHTENING TORQUES
2-18
Clutch spring bolt M6 6 8 Nm (0.8 m·kg, 5.8 ft·lb)
Clutch release cylinder bolt M6 3 10 Nm (1.0 m·kg, 7.2 ft·lb)
Clutch hose union bolt M10 1 30 Nm (3.0 m·kg, 22 ft·lb)
Bleed screw (clutch release cylin-
der)
M8 1 6 Nm (0.6 m·kg, 4.3 ft·lb)
Main axle assembly screw M6 3 12 Nm (1.2 m·kg, 8.7 ft·lb)
Stake
Middle drive pinion gear nut M22 1 110 Nm (11.0 m·kg, 80 ft·lb)
Use a
lock
washer.
Middle drive shaft bearing hous-
ing bolt
M6 3 12 Nm (1.2 m·kg, 8.7 ft·lb)
Bearing retainer (middle drive
shaft)
M88 1 110 Nm (11.0 m·kg, 80 ft·lb) Stake
Middle driven pinion gear nut M28 1 110 Nm (11.0 m·kg, 80 ft·lb)
Stake
Bearing retainer (middle driven
shaft)
M68 1 110 Nm (11.0 m·kg, 80 ft·lb) Stake
Middle driven shaft end cover
bolt
M8 3 25 Nm (2.5 m·kg, 18 ft·lb)
Shift drum retainer bolt M6 2 10 Nm (1.0 m·kg, 7.2 ft·lb)
Shift shaft spring stopper bolt M8 1 22 Nm (2.2 m·kg, 16 ft·lb)
Stator coil assembly bolt M6 3 10 Nm (1.0 m·kg, 7.2 ft·lb)
Gear position switch bolt M5 2 4 Nm (0.4 m·kg, 2.9 ft·lb)
Crankshaft position sensor bolt M5 2 4 Nm (0.4 m·kg, 2.9 ft·lb)
O
2
sensor
M18 1 45 Nm (4.5 m·kg, 32 ft·lb)
Intake air temperature sensor M12 1 18 Nm (1.8 m·kg, 13 ft·lb)
Cylinder identification sensor bolt M6 1 10 Nm (1.0 m·kg, 7.2 ft·lb)
Coolant temperature sensor M12 1 18 Nm (1.8 m·kg, 13 ft·lb)
Starter motor bolt M6 2 10 Nm (1.0 m·kg, 7.2 ft·lb)
Throttle position sensor screw M5 2 3.5 Nm (0.35 m·kg, 2.53 ft·lb)
Radiator bolt M6 3 10 Nm (1.0 m·kg, 7.2 ft·lb)
Radiator cover bolt M6 2 7 Nm (0.7 m·kg, 5.1 ft·lb)
Radiator bracket bolt M6 1 10 Nm (1.0 m·kg, 7.2 ft·lb)
Coolant reservoir bolt M6 2 7 Nm (0.7 m·kg, 5.1 ft·lb)
Coolant reservoir bracket bolt M6 2 7 Nm (0.7 m·kg, 5.1 ft·lb)
Item
Thread
size
Q’ty Tightening torque Remarks
LT
E
LT
LT
LT
LT
LT
LT
LT
LT
LT
