TIGHTENING TORQUES
2-22
T-bar bolt M10 3 37 Nm (3.7 m·kg, 27 ft·lb)
Rear fender bolt M6 3 7 Nm (0.7 m·kg, 5.1 ft·lb)
Rear fender nut M6 2 7 Nm (0.7 m·kg, 5.1 ft·lb)
Front wheel axle bolt M14 1 91 Nm (9.1 m·kg, 66 ft·lb)
See
NOTE.
Front wheel axle pinch bolt M8 4 21 Nm (2.1 m·kg, 15 ft·lb)
Front brake disc bolt M6 12 18 Nm (1.8 m·kg, 13 ft·lb)
Front wheel sensor bolt M8 1 30 Nm (3.0 m·kg, 22 ft·lb)
Rear wheel axle nut M18 1 125 Nm (12.5 m·kg, 90 ft·lb)
Rear wheel axle pinch bolt M8 1 23 Nm (2.3 m·kg, 17 ft·lb)
Rear brake disc bolt M6 6 18 Nm (1.8 m·kg, 13 ft·lb)
Rear wheel sensor bolt M8 1 30 Nm (3.0 m·kg, 22 ft·lb)
Brake torque rod nut M8 2 30 Nm (3.0 m·kg, 22 ft·lb)
Rear wheel dust cover screw M5 3 5 Nm (0.5 m·kg, 3.6 ft·lb)
Brake hose union bolt M10 14 30 Nm (3.0 m·kg, 22 ft·lb)
Brake pipe flare nut M10 11 19 Nm (1.9 m·kg, 13 ft·lb)
Front brake caliper bolt M10 4 40 Nm (4.0 m·kg, 29 ft·lb)
Front brake hose holder bolt M6 2 7 Nm (0.7 m·kg, 5.1 ft·lb)
Front brake caliper bleed screw M8 3 6 Nm (0.6 m·kg, 4.3 ft·lb)
Front brake pad bolt M10 2 17 Nm (1.7 m·kg, 12 ft·lb)
Rear brake caliper bolt M10 2 27 Nm (2.7 m·kg, 19 ft·lb)
Rear brake hose/rear wheel sen-
sor lead holder bolt
M6 1 7 Nm (0.7 m·kg, 5.1 ft·lb)
Rear brake caliper bleed screw M7 1 6 Nm (0.6 m·kg, 4.3 ft·lb)
Hydraulic unit nut M8 3 16 Nm (1.6 m·kg, 11 ft·lb)
Metering valve bolt M6 2 7 Nm (0.7 m·kg, 5.1 ft·lb)
Proportioning valve bolt M6 2 7 Nm (0.7 m·kg, 5.1 ft·lb)
Sidestand nut M10 1 58 Nm (5.8 m·kg, 42 ft·lb)
Sidestand switch screw M5 2 4 Nm (0.4 m·kg, 2.9 ft·lb)
Centerstand nut M10 4 55 Nm (5.5 m·kg, 40 ft·lb)
Centerstand bracket nut M10 2 55 Nm (5.5 m·kg, 40 ft·lb)
Brake pedal bolt M6 1 8 Nm (0.8 m·kg, 5.8 ft·lb)
Right footrest bracket bolt M8 2 28 Nm (2.8 m·kg, 20 ft·lb)
Rear brake master cylinder bolt M8 2 18 Nm (1.8 m·kg, 13 ft·lb)
Rear brake master cylinder lock-
nut
M8 1 16 Nm (1.6 m·kg, 11 ft·lb)
Left footrest assembly bolt M8 2 28 Nm (2.8 m·kg, 20 ft·lb)
Left footrest assembly bolt M10 1 49 Nm (4.9 m·kg, 35 ft·lb)
Left footrest assembly/sidestand
bolt
M10 2 65 Nm (6.5 m·kg, 47 ft·lb)
Item
Thread
size
Q’ty Tightening torque Remarks
LT
LT
LT
LS
LS
LT
LT
