CARBURETOR SYNCHRONIZATION
1':gS
I_I
6.Adjust:
• Carburetor synchronization
**********************************
Adjustment
steps:
.Synchronize
carburetor
#1
to
carburetor
#2
by
turning
the
synchronizing screw
CD
until
both gauges read the same.
• Rev the engine
two
or
three times, each
time
for
less than a second, and check the
synchronization again.
Vacuum pressure
at
idle
speed:
29.0
kPa
(220
mm
Hg, 8.7
in
Hg)
NOTE:
_
The difference between the
two
carburetors
should
not
exceed 1.33
kPa
(10
mm
Hg,
0.39 in Hg).
**********************************
7.Check:
• Engine idling speed
Out
of
specification
~
Adjust.
8.Stop the engine and detach
the
measur-
ing equipment.
9.Adjust
• Throttle cable free play
Refer
to
"THROTTLE CABLE ADJUST-
MENT".
Free
play
(throttle
cable):
4
....
6
mm
(0.16
....
0.24 in)
At
throttle
grip
flange
10.lnstall:
• Vacuum plugs
3-9
