5-3
Order Job name/Part name Q’ty Remarks
13
14
15
16
Diaphragm set
Throttle position sensor
Pilot screw
Main air jet
1
1
1
1
Refer to “CARBURETOR ASSEMBLY”.
Refer to “THROTTLE POSITION
SENSOR (TPS) INSPECTION AND
ADJUSTMENT”.
Refer to “CARBURETOR ASSEMBLY”.
For assembly, reverse the disassembly
procedure.
CARBURETOR
CARB
