MAINTENANCE SPECIFICATIONS
SPEC
Item Standard Limit
Compressed pressure IN
(installed)
EX
Tilt limit
*
IN
EX
Direction of winding
(top view)IN
EX
21.8  25.6 kg
21.8  25.6 kg


Counter clockwise
Counter clockwise


2.5 /1.9
mm
2.5 /1.9
mm


Piston:
Piston to cylinder clearance
Piston size “D”
Measuring point “H”
Oversize 2nd
Oversize 4th
Piston off-set
Piston pin bore inside diameter
Piston pin outside diameter
0.035  0.055 mm
80.90  80.95 mm
6 mm
81.5 mm
82 mm
0 mm
20.004  20.015 mm
19.995  20.000 mm
0.15 mm







Piston rings:
Top ring:
Type
Dimensions (B  T)
End gap (installed)
Side clearance (installed)
Plain
1.2  3.2 mm
0.15  0.30 mm
0.03  0.07 mm


0.55 mm
0.12 mm
